Ford F-150 Towing Capacity: Discover Its Impressive Features
The 2024 Ford F-150 towing capacity sets an impressive standard in the world of light-duty pickup trucks: the F-150 lineup combines raw power with cutting-edge technology to meet all of your hauling needs. Whether towing a boat or RV for a weekend getaway or hauling heavy equipment to your work site, the F-150 provides robust capabilities, including a maximum towing capacity of 13,500 pounds.1
We put this guide together here at Wallace Ford of Kingsport to help you learn how the the Ford brand creates an enhanced towing experience with advanced features, compare values by model year and engine, and peruse some general safety tips. You'll be ready to hit the road with a load in tow when you upgrade to your next Ford F-150.
Ford F-150 Towing Capacity Overview
The 2024 Ford F-150 tow capacity reaches an impressive 13,500 pounds1 maximum. This is plenty of power for easily hauling your boat, several ATVs, a camper, or work equipment.
Eight well-equipped trim levels and six engine options provide plenty of unique configurations. The 2024 Ford F-150 for sale truly has something for everyone.
2024 Ford F-150 Towing Capacity by Engine
The Ford F-150 towing specs vary by engine, and with six options, there's a lot to unpack. The engine options and their towing and performance specs are as follows:
- 2.7-liter EcoBoost V-6: 325 horsepower, 400 pound-feet of torque, and an 8,400-pound1 towing capacity
- 3.5-liter EcoBoost V-6: 400 horsepower, 500 pound-feet of torque, and a 13,500-pound1 towing capacity
- 5.0-liter Ti-VCT V-8: 400 horsepower, 410 pound-feet of torque, and a 12,900-pound1 towing capacity.
- 3.5-liter PowerBoost Full Hybrid: 430 horsepower, 570 pound-feet of torque, and an 11,200-pound1 towing capacity
- High-Output 3.5-liter EcoBoost V-6 (Raptor Only): 450 horsepower, 510 pound-feet of torque, and an 8,200-pound1 towing capacity
- 5.2-liter Supercharged V-8 (Raptor R Only): 720 horsepower, 640 pound-feet of torque, and an 8,700-pound1 towing capacity
In addition to its heavy towing capabilities, the 2024 Ford F-150 truck offers up to 2,445 pounds2 of payload capacity when equipped with the 3.5-liter EcoBoost V-6 engine.
Ford F-150 Trim Levels
The 2024 Ford F-150 towing capacity varies depending on which model you select out of the lineup of eight trim levels. Other factors that affect the tow rating of a particular model include the engine option, drivetrain configuration, and truck body style. If you are buying a truck for maximum towing capacity, it's essential to understand how each element plays into the overall towing weight limit of your ideal model. The 2024 Ford F-150 trims include:
- 2024 Ford F-150 XL
- 2024 Ford F-150 STX
- 2024 Ford F-150 XLT
- 2024 Ford F-150 TREMOR
- 2024 Ford F-150 LARIAT
- 2024 Ford F-150 King Ranch
- 2024 Ford F-150 Platinum
- 2024 Ford F-150 Raptor
If you want to take full advantage of all the towing capacity this truck offers, select a model with a SuperCrew cab, 6-foot-5-inch box, 4x4 drivetrain, and the available 3.5-liter EcoBoost V-6 engine with the Tow/Haul Package and Max Tow Axle upgrade.
Explore the Impressive Ford F-150 Towing Features
The F-150 is full of towing technology features to help make towing easier and more intuitive, even if it's your first time hauling a trailer. It can help you hitch up, maneuver your trailer, and tow with confidence via the following standard and available amenities:
- Pro Trailer Backup Assist: Control the direction of your trailer in reverse simply by turning a dial.
- Pro Trailer Hitch Assist: Give up control and let your pickup automatically steer, accelerate, and brake for you as it positions your truck into place for easy hitching.
- Dynamic Hitch Assist: Align your truck hitch with your trailer using on-screen guidelines.
- Smart Hitch: Receive tongue weight values automatically as your trailer lowers into place, ensuring the tongue weight of your tow load is within your truck's capabilities.
- Onboard Scales: Estimate your payload weight automatically to make sure you're within your model's maximum capacity.
While you may be able to opt for some towing features individually, we recommend springing for the Max Tow Package, aka the Tow/Haul Package, and the Max Tow Axle upgrade. They provide everything you'll need to elevate your towing capabilities and safety while making the job as simple as possible.
Ford F-150 Towing Capacity Chart by Year
Ford truck towing performance varies by year. If you're considering a used model, use our chart below to compare various model years, their available powertrains, and the maximum values for each.
2024 |
||
|---|---|---|
| Engine Options | Max Towing | Max Payload |
| 2.7L EcoBoost V-6 | 8,400 lbs1 | 1,775 lbs2 |
| 3.5L EcoBoost V-6 | 13,500 lbs1 | 2,445 lbs2 |
| 3.5L PowerBoost full hybrid V-6 | 11,200 lbs1 | 1,775 lbs2 |
| 5.0L Ti-VCT V-8 | 12,900 lbs1 | 2,330 lbs2 |
| 3.5L EcoBoost H.O. V-6 | 8,200 lbs1 | 1,405 lbs2 |
| 5.2L supercharged V-8 | 8,700 lbs1 | 1,410 lbs2 |
2023 |
||
| Engine Options | Max Towing | Max Payload |
| 3.3L Ti-VCT V-6 | 8,200 lbs1 | 1,995 lbs2 |
| 2.7L EcoBoost V-6 | 10,100 lbs1 | 2,465 lbs2 |
| 3.5L EcoBoost V-6 | 14,000 lbs1 | 3,235 lbs2 |
| 3.5L PowerBoost full hybrid V-6 | 12,700 lbs1 | 2,120 lbs2 |
| 5.0L Ti-VCT V-8 | 13,000 lbs1 | 3,315 lbs2 |
| 3.5L EcoBoost H.O. V-6 | 8,200 lbs1 | 1,445 lbs2 |
| 5.2L supercharged V-8 | 8,700 lbs1 | 1,400 lbs2 |
2022 |
||
| Engine Options | Max Towing | Max Payload |
| 3.3L Ti-VCT V-6 | 8,200 lbs1 | 1,965 lbs2 |
| 2.7L EcoBoost V-6 | 10,100 lbs1 | 2,480 lbs2 |
| 3.5L EcoBoost V-6 | 14,000 lbs1 | 3,250 lbs2 |
| 3.5L PowerBoost full hybrid V-6 | 12,700 lbs1 | 2,120 lbs2 |
| 5.0L Ti-VCT V-8 | 13,000 lbs1 | 3,325 lbs2 |
| 3.5L EcoBoost H.O. V-6 | 8,200 lbs1 | 1,400 lbs2 |
2021 |
||
| Engine Options | Max Towing | Max Payload |
| 3.3L Ti-VCT V-6 | 8,200 lbs1 | 1,985 lbs2 |
| 2.7L EcoBoost V-6 | 10,100 lbs1 | 2,480 lbs2 |
| 3.5L EcoBoost V-6 | 14,000 lbs1 | 3,250 lbs2 |
| 3.5L PowerBoost full hybrid V-6 | 12,700 lbs1 | 2,120 lbs2 |
| 5.0L Ti-VCT V-8 | 13,000 lbs1 | 3,325 lbs2 |
| 3.0L turbo-diesel V-6 | 12,100 lbs1 | 1,840 lbs2 |
2020 |
||
| Engine Options | Max Towing | Max Payload |
| 3.0L turbo-diesel V-6 | 7,700 lbs1 | 1,990 lbs2 |
| 2.7L EcoBoost V-6 | 9,000 lbs1 | 2,470 lbs2 |
| 3.5L EcoBoost V-6 | 13,200 lbs1 | 3,230 lbs2 |
| 5.0L Ti-VCT V-8 | 11,500 lbs1 | 3,270 lbs2 |
| 3.0L turbo-diesel V-6 | 11,500 lbs1 | 2,020 lbs2 |
| 3.5L EcoBoost H.O. V-6 | 11,100 lbs1 | 1,520 lbs2 |
2019 |
||
| Engine Options | Max Towing | Max Payload |
| 3.3L Ti-VCT V-6 | 7,700 lbs1 | 1,990 lbs2 |
| 2.7L EcoBoost V-6 | 9,000 lbs1 | 2,470 lbs2 |
| 3.5L EcoBoost V-6 | 13,200 lbs1 | 3,230 lbs2 |
| 5.0L Ti-VCT V-8 | 11,500 lbs1 | 3,270 lbs2 |
| 3.0L turbo-diesel V-6 | 11,500 lbs1 | 2,020 lbs2 |
| 3.5L EcoBoost H.O. V-6 | 11,100 lbs1 | 1,530 lbs2 |
2018 |
||
| Engine Options | Max Towing | Max Payload |
| 3.3L Ti-VCT V-6 | 7,700 lbs1 | 1,990 lbs2 |
| 2.7L EcoBoost V-6 | 9,000 lbs1 | 2,470 lbs2 |
| 3.5L EcoBoost V-6 | 13,200 lbs1 | 3,230 lbs2 |
| 5.0L Ti-VCT V-8 | 11,600 lbs1 | 3,270 lbs2 |
| 3.5L EcoBoost H.O. V-6 | 8,000 lbs1 | 1,200 lbs2 |
2017 |
||
| Engine Options | Max Towing | Max Payload |
| 3.5L Ti-VCT V-6 | 7,600 lbs1 | 1,910 lbs2 |
| 2.7L EcoBoost V-6 | 8,500 lbs1 | 2,210 lbs2 |
| 3.5L EcoBoost V-6 | 12,200 lbs1 | 3,220 lbs2 |
| 5.0L Ti-VCT V-8 | 11,000 lbs1 | 3,270 lbs2 |
| 3.5L EcoBoost H.O. V-6 | 8,000 lbs1 | 1,200 lbs2 |
2016 |
||
| Engine Options | Max Towing | Max Payload |
| 3.5L Ti-VCT V-6 | 7,600 lbs1 | 1,910 lbs2 |
| 2.7L EcoBoost V-6 | 8,500 lbs1 | 2,210 lbs2 |
| 3.5L EcoBoost V-6 | 12,200 lbs1 | 3,220 lbs2 |
| 5.0L Ti-VCT V-8 | 11,000 lbs1 | 3,270 lbs2 |
| 3.5L EcoBoost H.O. V-6 | 8,000 lbs1 | 1,200 lbs2 |
Towing Tips and Safety
Towing with your Ford F-150 truck can be a breeze if you follow a few essential tips and safety guidelines. Ensuring a smooth and safe towing experience will protect your cargo, vehicle, and passengers, helping you make the most out of this pickup's impressive capabilities. Here are some crucial tips to keep in mind:
- Know Your Limits: Always be aware of the exact towing and payload capacities of your specific F-150 model and configuration, and never exceed them. Overloading your truck bed or hitch can lead to dangerous driving conditions and potential personal, vehicle, or cargo damage.
- Distribute Weight Evenly: When towing, always ensure your load is balanced. Weight in a trailer should be balanced side to side, and the majority of the weight should be closest to the truck to avoid dangerous trailer sway.
- Check Your Equipment: Before hitting the road, you should inspect your hitch, trailer lights, brakes, and safety chains. Always make sure everything is in proper working order every single time you tow.
- Use Towing Mirrors: Extended towing mirrors can help increase visibility when towing a large or long trailer and help you keep an eye on your blind spots.
- Drive Cautiously: Driving a truck while towing a trailer is not the same as driving an unloaded truck. When towing, be sure to take it slow and steady. Maintain a safe following distance from other vehicles and brake gently long before you need to come to a full stop to give yourself more control and reaction time.
- Practice Makes Perfect: If you're new to towing, take some time to practice in a safe, open area with a trailer attached. It may feel nerve-wracking at first, but by following towing safety tips and utilizing the advanced towing technology of the Ford F-150 truck, you'll be a towing pro in no time.
Being able to tow equipment for work or leisure opens up a world of possibilities. If you want to try it out without the long-term commitment of ownership, you can lease a new Ford F-150 truck to see how you like it.
Experience the Power and Performance of the New Ford F-150
With a 13,500-pound1 maximum towing capacity, the 2024 Ford F-150 truck stands primed and ready to join you on every journey. Whether you're looking for a truck to haul heavy loads for work or to embark on an adventure, you can't go wrong with this truck.
Take the next step and finance your new Ford F-150 at Wallace Ford of Kingsport. Our team is dedicated to helping you find the perfect model that fits your needs and budget. Experience the strength, reliability, and performance of the new Ford F-150 for yourself.
Frequently Asked Questions
What is the towing capacity of a 2024 Ford F-150 truck?
The towing capacity of the 2024 Ford F-150 truck ranges from 8,200 pounds to a maximum of 13,500 pounds.1 This truck features eight trim levels with six engine options and multiple body configurations, each offering different towing specs. The Ford F-150 provides a maximum payload capacity of 2,445 pounds2 and has multiple advanced towing technologies that make hauling and towing easier.
What is the maximum payload capacity of the Ford F-150?
The maximum payload capacity of the 2024 Ford F-150 truck is 2,445 pounds2 when equipped with the 3.5-liter EcoBoost V-6 engine. In addition to the impressive payload capacity, this truck has technology features like Onboard Scales, which help approximate your payload weight. This feature lets you know whether or not your load is balanced and helps you stay within your truck's capabilities.
Which F-150 engine is best for towing?
If you want to take advantage of the maximum towing capacity of the 2024 Ford F-150, the 3.5-liter EcoBoost V-6 engine provides the most towing power. This engine offers up to 13,500 pounds1 of towing capacity and a maximum payload capacity of 2,445 pounds.2 Maximum towing and payload capacities vary based on accessories and vehicle configurations, including cab style, drivetrain, and more.
1When properly equipped. See dealer for details.
2Maximum payload capabilities are for properly equipped vehicles with required equipment and vary based on vehicle configuration, accessories, and option content. Horsepower, torque, payload and towing are independent attributes and may not be achieved simultaneously.
