Ford F-150 Towing Capacity: Discover Its Impressive Features

Front quarter view of a Ford F-150 Platinum towing a sport boat past a lakeside.

The maximum Ford F-150 towing capacity is 13,500 pounds,1 while the truck's maximum payload capacity is a stout 2,440 pounds.2 These stats are impressive without a doubt, but when you consider that they are also the best stats in this class,3 they become simply unbeatable. To see the details involved with the truck's weight limit and more, read on and visit us at Wallace Ford of Kingsport to test-drive a new or used F-150.

Shop New Ford F-150 Inventory
Ford F-150 Deals

2026 Ford F-150 Towing Capacity by Engine

The first factor behind the 2026 Ford F-150 towing capacity is which engine you select. Each is a solid source of power, as you can see in these specs:

  • 2.7-liter EcoBoost V-6: 325 horsepower and 400 pound-feet of torque - maximum towing capacity of 8,400 pounds1
  • 5.0-liter V-8: 400 horsepower and 410 pound-feet of torque - maximum towing capacity of 12,900 pounds1
  • 3.5-liter EcoBoost V-6: 400 horsepower and 500 pound-feet of torque - maximum towing capacity of 13,500 pounds1
  • 3.5-liter PowerBoost Hybrid V-6: 430 horsepower and 578 pound-feet of torque - maximum towing capacity of 11,200 pounds1
  • 3.5L EcoBoost High-Output V-6: 450 horsepower and 510 pound-feet of torque - maximum towing capacity of 8,200 pounds1
  • 5.2-liter Supercharged V-8: 720 horsepower and 640 pound-feet of torque - maximum towing capacity of 8,700 pounds1

For an F-150 that can manage the heaviest tow load, seek one with the 3.5-liter EcoBoost V-6 or the 5.0-liter V-8.

Front quarter view of a Ford F-150 Platinum in Ruby Red Metallic towing a motorboat up a concrete boat ramp.

Ford F-150 Trim Levels: Which Is Best for Towing?

The 2026 Ford F-150 is available in eight trims, which are as follows:

  • XL
  • STX
  • XLT
  • Lariat
  • Tremor
  • King Ranch
  • Platinum
  • Raptor

To reach the maximum Ford F-150 towing capacity of 13,500 pounds,1 you'll need to find a model configured with the 3.5-liter EcoBoost engine, 4WD, a SuperCrew cab, and a 6.5-foot bed. While past model years required the Max Trailer Tow Package, the new F-150 needs the "Max Tow Axle" and "Tow/Haul Package" to reach its maximum towing capacity, rather than the prior max tow package.

Multiple trims can be had with this configuration, including the XLT, Lariat, King Ranch, and Platinum. We recommend the XLT for drivers who prefer a more affordable and versatile truck; the Lariat is a great upgrade if you want all that with some more luxury added on. The King Ranch and Platinum, meanwhile, are supremely luxurious but cost more than the XLT and Lariat.

Another trim-based factor to consider regarding the 2026 Ford F-150 for sale is the lineup of towing features, such as the available Pro Trailer Backup Assist, which makes the hardest part of towing a much simpler task, and the Pro Trailer Hitch Assist, which does the same for the initial connection with a trailer. These towing assists are optional for the XLT but come standard on the Lariat and higher.

Front quarter tracking view of a Ford F-150 XLT in Argon Blue Metallic towing a large travel trailer on a highway.Front tracking view of a Ford F-150 Platinum in Marsh Gray towing an Airstream trailer down a wooded highway.

Ford F-150 Towing Capacity Chart by Year

2026
Engine Options Max Towing Max Payload
2.7L EcoBoost V-6 8,400 lbs1 1,775 lbs2
3.5L EcoBoost V-6 13,500 lbs1 2,440 lbs2
3.5L PowerBoost full hybrid V-6 11,200 lbs1 1,740 lbs2
5.0L Ti-VCT V-8 12,900 lbs1 2,235 lbs2
3.5L EcoBoost H.O. V-6 8,200 lbs1 1,410 lbs2
5.2L supercharged V-8 8,700 lbs1 1,410 lbs2

2025
Engine Options Max Towing Max Payload
2.7L EcoBoost V-6 8,400 lbs1 1,775 lbs2
3.5L EcoBoost V-6 13,500 lbs1 2,445 lbs2
3.5L PowerBoost full hybrid V-6 11,200 lbs1 1,815 lbs2
5.0L Ti-VCT V-8 12,900 lbs1 2,225 lbs2
3.5L EcoBoost H.O. V-6 8,200 lbs1 1,405 lbs2
5.2L supercharged V-8 8,700 lbs1 1,410 lbs2

2024
Engine Options Max Towing Max Payload
2.7L EcoBoost V-6 8,400 lbs1 1,775 lbs2
3.5L EcoBoost V-6 13,500 lbs1 2,445 lbs2
3.5L PowerBoost full hybrid V-6 11,200 lbs1 1,775 lbs2
5.0L Ti-VCT V-8 12,900 lbs1 2,330 lbs2
3.5L EcoBoost H.O. V-6 8,200 lbs1 1,405 lbs2

2023
Engine Options Max Towing Max Payload
3.3L Ti-VCT V-6 8,200 lbs1 1,995 lbs2
2.7L EcoBoost V-6 10,100 lbs1 2,465 lbs2
3.5L EcoBoost V-6 14,000 lbs1 3,235 lbs2
3.5L PowerBoost full hybrid V-6 12,700 lbs1 2,120 lbs2
5.0L Ti-VCT V-8 13,000 lbs1 3,315 lbs2
3.5L EcoBoost H.O. V-6 8,200 lbs1 1,445 lbs2

2022
Engine Options Max Towing Max Payload
3.3L Ti-VCT V-6 8,200 lbs1 1,965 lbs2
2.7L EcoBoost V-6 10,100 lbs1 2,480 lbs2
3.5L EcoBoost V-6 14,000 lbs1 3,250 lbs2
3.5L PowerBoost full hybrid V-6 12,700 lbs1 2,120 lbs2
5.0L Ti-VCT V-8 13,000 lbs1 3,325 lbs2
3.5L EcoBoost H.O. V-6 8,200 lbs1 1,400 lbs2

2021
Engine Options Max Towing Max Payload
3.3L Ti-VCT V-6 8,200 lbs1 1,985 lbs2
2.7L EcoBoost V-6 10,100 lbs1 2,480 lbs2
3.5L EcoBoost V-6 14,000 lbs1 3,250 lbs2
3.5L PowerBoost full hybrid V-6 12,700 lbs1 2,120 lbs2
5.0L Ti-VCT V-8 13,000 lbs1 3,325 lbs2
3.0L turbo-diesel V-6 12,100 lbs1 1,840 lbs2

2020
Engine Options Max Towing Max Payload
3.0L turbo-diesel V-6 7,700 lbs1 1,990 lbs2
2.7L EcoBoost V-6 9,000 lbs1 2,470 lbs2
3.5L EcoBoost V-6 13,200 lbs1 3,230 lbs2
5.0L Ti-VCT V-8 11,500 lbs1 3,270 lbs2
3.0L turbo-diesel V-6 11,500 lbs1 2,020 lbs2
3.5L EcoBoost H.O. V-6 11,100 lbs1 1,520 lbs2

2019
Engine Options Max Towing Max Payload
3.3L Ti-VCT V-6 7,700 lbs1 1,990 lbs2
2.7L EcoBoost V-6 9,000 lbs1 2,470 lbs2
3.5L EcoBoost V-6 13,200 lbs1 3,230 lbs2
5.0L Ti-VCT V-8 11,500 lbs1 3,270 lbs2
3.0L turbo-diesel V-6 11,500 lbs1 2,020 lbs2
3.5L EcoBoost H.O. V-6 11,100 lbs1 1,530 lbs2

2018
Engine Options Max Towing Max Payload
3.3L Ti-VCT V-6 7,700 lbs1 1,990 lbs2
2.7L EcoBoost V-6 9,000 lbs1 2,470 lbs2
3.5L EcoBoost V-6 13,200 lbs1 3,230 lbs2
5.0L Ti-VCT V-8 11,600 lbs1 3,270 lbs2
3.5L EcoBoost H.O. V-6 8,000 lbs1 1,200 lbs2

Towing Tips and Safety

Before you buy or lease a new Ford F-150 truck and use its impressive towing capacity, here are some safety tips to consider:

  • Know Your Limits: Do not exceed your specific Ford F-150 towing specs or payload rating.
  • Distribute Weight Evenly: Both tongue weight and trailer weight should be balanced according to official guidelines.
  • Check Your Equipment: Inspect your hitch, trailer, trailer lights, and other gear regularly.
  • Drive Cautiously: Be aware that towing makes your truck accelerate more slowly, brake less effectively, and turn wider.

If you're ready to lease or finance your new Ford F-150, give the Wallace Ford of Kingsport team a call or visit us in person to get started!

Rear view of a Ford F-150 Lariat in Ruby Red Metallic with its tailgate open while people unload outdoor gear in the desert.

Frequently Asked Questions

What is the towing capacity of a 2026 Ford F-150 truck?

The towing capacity of a 2026 Ford F-150 truck will vary depending on how it is configured. The maximum tow rating of the latest F-150, though, is a best-in-class 13,500 pounds,3 proving that this iconic Ford truck can do more than the competition.

What is the maximum payload capacity of the Ford F-150?

The Ford F-150 has a maximum payload capacity of 2,440 pounds,2 which is a best-in-class figure for full-size light-duty trucks.3

Which F-150 engine is best for towing?

The 3.5-liter EcoBoost V-6 is the best F-150 engine for towing, as it can achieve the highest maximum Ford F-150 tow capacity (a best-in-class 13,500 pounds3). The 5.0-liter V-8 engine is also a great choice due to its maximum tow rating of 12,900 pounds.1

1When properly equipped. See dealer for details.

2Maximum payload capabilities are for properly equipped vehicles with required equipment and vary based on vehicle configuration, accessories, and option content. Horsepower, torque, payload and towing are independent attributes and may not be achieved simultaneously.

3Maximum towing capabilities are for properly equipped vehicles with required equipment and a 150-lb. driver and passenger and vary based on cargo, vehicle configuration, accessories, option content and number of passengers. Maximum payload capabilities are for properly equipped vehicles with required equipment and vary based on vehicle configuration, accessories, and option content. Horsepower, torque, payload and towing are independent attributes and may not be achieved simultaneously. For additional information, see your Ford Dealer.
